TL-26M0540D_F3101B-S2.wnc-1203Apr04.htm

Job Sheet-26M0540D_F3101B-S2.wnc

Path : D:\sejong\model\2026\26M0540D\3101B\3101-4\

Geometry : 26M0540D_F3101B_CNV_260313.x_t.wnc

P/G : M041203Apr04.htm

warning,,,X Eccentric,,, :X_Center : -251.42
..

---|Warning---Z_Max: : 164.03 ---
---|Warning---Z_Min : : -114.97 ---

	No.						Krpm	Feed Rate	Approach Rate	Z-Step	Angle A,B,C
10	400, 401, 402, 403	10	Bull-nose D 26.00 r 1.00	26.00	1.00	$images\outil400.tool.png$	3.1	2300	2500
10	407	10	Bull-nose D 25.96 r 1.00	25.96	1.00	$images\outil407.tool.png$	3.1	2300	2500
10	408	10	Bull-nose D 25.96 r 1.00	25.96	1.00	$images\outil408.tool.png$	3.1	2300	2500
10	409	10	Bull-nose D 25.96 r 1.00	25.96	1.00	$images\outil409.tool.png$	3.1	2300	2500
10	411	10	Bull-nose D 26.00 r 1.00	26.00	1.00	$images\outil411.tool.png$	3.1	2300	2500	0.45
11	410, 420	11	Bull-nose D 17.00 r 1.00	17.00	1.00	$images\outil410.tool.png$	4.2	2500	2500
12	404, 405, 415, 416, 417, 418, 419	12	Ball-end D 10.00	10.00		$images\outil404.tool.png$	6.2	2300	2300
13	406	13	Bull-nose D 33.00 r 1.00	33.00	1.00	$images\outil406.tool.png$	2.6	2200	2500
13	412	13	Bull-nose D 32.98 r 1.00	32.98	1.00	$images\outil412.tool.png$	2.6	2200	2500	0.40
14	413, 422, 423	14	Ball-end D 6.00	6.00		$images\outil413.tool.png$	6.5	2000	2000
15	414, 424	15	Ball-end D 3.00	3.00		$images\outil414.tool.png$	7.5	1800	2000
16	421	16	Bull-nose D 21.00 r 1.00	21.00	1.00	$images\outil421.tool.png$	3.6	2500	2500
17	425	17	Ball-end D 2.00	2.00		$images\outil425.tool.png$	7.9	1200	1500
18	426, 427, 428, 429, 430, 431	18	Ball-end D 1.00	1.00		$images\outil426.tool.png$	7.9	800	1200	0.02
19	432, 433, 434	19	Ball-end D 1.00	1.00		$images\outil432.tool.png$	7.9	800	1200
WorkNC Tool List: 10, 11, 12, 13, 14, 15, 16, 17, 18, 19
Same tool number with different values.
