Job Sheet-25M3340D_F04_Z01_25090

Path : D:\sejong\model\2025\25M3340D_SU\250909\04\04-2\ Geometry : 25M3340D_F04_Z01_250908.x_t.wnc P/G : M041203Sep10.htm
X_Min : -1000.000,          X_Set_A :   -1005.000 Y_Max : 555.000,          Y_Set_A :   560.000 Z_Max : 349.751
X_Max : 1000.000,          X_Set_A :   1005.000 Y_Min : -555.000,          Y_Set_A :   -560.000 Z_Min : -0.000
X_Center : 0.000 Y_Center : 0.000
X_Length 2000.00 Y_Length 1110.00 Z_Length 349.75

images/basepart.png

..
===> :Z_Min = 0.00,,,,,,,,,,Z_Min: : -0.00
---MC1203-25M3340D_F04_Z01_25090Sep10.jpg---- , Programmer's Comment : ??¢¯©ª¨¡?
NCD Toolpath Type T_No Cutter Image D,¢± R_cn Holder Safe Tool Length Zmin
(R_cen) 		Stock Krpm Time
O6701 Global Rough/Rerough 1 ToolpathCutterShape 26.00 2.00 R:2.00 Bull-nose, A05-BT50_C25-200S-SRS 121.20 75.00 0.20 1.6 00:15
O6702 Z-Level Finishing 2 ToolpathCutterShape 21.00 1.00 R:1.00 Bull-nose, B03-BT50_HF20-165H-SRS 121.00 75.00 0.00 3.6 00:05
1 2, Selected : 35795.60mm Total Time : 00:20
(Each-PP) : 54_G154 ¡Þ¡Þ [ S1250-#3 ] ¡Þ¡Þ ,   Saved File Name : M0412032Sep10.htm, Save time : 10:39:56 , Saved Counter : 2
---Sort By Tool_NO--- Se Jong Precision Machinery Co. LTD, Tel : 031 666 1325, Fax : 031 666 1327 ---EnLarge Image---
